General Data
- Operating Temparature Range (C): -25-60C, >45C Derating
- Cooling: Fan
- Noise(dB): <30
- Communication with BMS: RS485;CAN
- Weight (Kg): 20.5
- Size (Length x Widthx Height mm): 670 x 420 x 233mm
- Protection Degree: IP65
- Installation Style: Wall mounted
- Warranty: 5 Years
Battery Input Data
- Battery Type: Lead-acid or Li-lon.
- Battery Voltage Range (V): 40-60V.
- Max.Charging Current (A): 190A.
- Max.Discharging Current (A): 190A.
- Charging Curve: 3 Stages/Equalization.
- External Temperature Sensor: Optional.
- Charging Strategy for Li-Ion Battery: Self-adaption to BMS.
PV String Input Data
- Max. DC Input Power (W): 10400W.
- PV Input Voltage (V): 370V (100V – 500V).
- MPPT Range (V): 125V – 425V.
- Full Load DC Voltage Range: 240V – 425V.
- Start-up Voltage (V): 150V.
- PV Input Current (A): 18A 18A.
- No.of MPPT Trackers: 2.
- No.of strings per MPPT Tracker: 2 2.
AC Output Data
- Rated AC Output and UPS Power (W): 8000W.
- Max. AC Output Power (W): 8800W.
- Peak Power (off grid): 2 times of rated power, 10 S.
- AC Output Rated Current (A): 33.4A/35A.
- Max. AC Current (A): 38.3A/40A.
- Max Continuous AC Passthrough (A): 50A.
- Power Factor: 0.8 leading to 0.8 lagging.
- Output Frequency and Voltage: 50/60Hz; 120/240Vac(split phase), 208Vac(2/3 phase),230Vac(single phase).
- Grid Type: Split phase / 2/3 phase / Single Phase.
- Current Harmonic Distortion: THD<3%(Linear Load<1.5%).
